  • LinerGrip can be produced to suit almost any combination of configurations, specific to site requirements
  • Supports the PE pipe as it exits the host main
  • Prevents the PE pipe from retracting into the host pipe and seals the gap between the two pipes to ensure no leaks or ingress of ground water
  • Uses MaxiFit components for connection to the host main and therefore benefits from the tolerance of the MaxiFit range
Pipe Materials
Ductile Iron Cast Iron Asbestos Cement Concrete PE Steel
Applications
Water

1 Corrosion Protection

Metal components are coated with Rilsan Nylon 11 which is WRAS approved for use with potable water. The nuts and bolts are Sheraplex coated to WIS 4-52-03, offering true long term protection against corrosion, impact and abrasion to ensure continued reliable performance.

2 Stability

LinerGrip seals onto the outside of the host main, which stabilises the entire fitting, as well as preventing the possibility of ingress of ground water into the gap between host and liner pipes.

3 Easy Installation

LinerGrip is a mechanical connection, and as such requires no specialist equipment, other than a torque wrench.
